4LM DC Traction Power Upgrade

21/08/2018

Project Overview

As part of London Underground’s larger scheme to upgrade the Sub-Surface Lines (SSL) to enable the operation of new S-Stock trains, AmcoGiffen were contracted to upgrade the power supply system at various London Underground sub-stations and underground stations, to increase the nominal mainline voltage from 630v to 750v Direct Current (DC).

AmcoGiffen’s Scope of Works

We were selected to deliver the reinforcement of the DC track feeder cables that deliver the traction supply from each sub-station to the sub-surface railway through the installation of an additional 935mm traction cables per pole, installation of track isolating switches and the associated Cable Route Management System (CRMS).

Our further scope of works included:

Design works where required
Termination of negative and positive traction continuity links to conductor rails
Installation of bespoke CRMS
Minor civils work
Fire stopping of cable penetrations to London Underground Standard 1-083 (2 hour fire protection)
Testing and commissioning of DC feeder cables and all installations
Production of O&M manuals, as-built drawings and test sheets
Decommissioning, removal and disposal of existing non-compliant DC track feeder cables and track isolating switches
Replacement of PILC/PIAC cables where present

I would like to express my gratitude to the [AmcoGiffen] project team responsible for the delivery of the DC Power Package 2 works as part of the 4LM DC ETE Project… The project team proved themselves to be competent and reliable suppliers for this project and should be proud of their achievements.

Kenneth Sloan, 4LM Power Portfolio

Innovation Applied

Continually embracing and implementing new and more effective ways of providing enhanced project delivery, AmcoGiffen created and installed a bespoke Cable Route Management System at Embankment Station.

Customising our system design to seamlessly integrate with the infrastructure to allow for increased mainline voltage, we successfully delivered a superior and innovative solution.

Benefits Provided

Facilitating the continuation of London Underground’s Sub-Surface Upgrade Programme (SUP), our team liaised efficiently with the client to ensure the successful delivery of the upgrade, on time and to budget.

Benefits of the project include:

Reduction in journey time for passengers
Assist in the instigation of new, larger S-Stock trains which will increase capacity to support the projected growth for London’s population
Modernise London Underground travel Further benefits provided by AmcoGiffen:
A robust and comprehensive understanding of the technical scope
A strong commitment to around the clock health and safety
The ability to promptly adjust to project modifications
A client-first commitment and excellence driven philosophy
